Products specifications
| Max. Weight Per Door | 330lbs. [150kg] |
| Max. Door Width | 36" (3'- 0") [914mm] |
| Min. Soft Close Door Width | 32" (2'- 8") [813mm] |
| Max. Door Height | 84" (7'-0") [2134mm] |
| Door Thickness | 1-1/8" [29mm] to <br>2-1/4" [57mm]<br> |
| Min. Wall Structure Thickness | 5-1/2" (2 x 6) [140mm] |
Related Products
2050PLBG Converging Door Kit
$17.83
2000/2060 Series Pocket Door Frame Converging Door Kit.
Hardware required to convert 2 single Pocket Door Frames into 1 Converging Pocket Door Installation.
Hardware required to convert 2 single Pocket Door Frames into 1 Converging Pocket Door Installation.
2027SD-1 Pocket Door Part Set
$84.84
200PD, 200PDSC, 2000, 2000SC, 2060, 2060SC Series Pocket Door Part Set
20312006 Replacement Header Bag
$21.25
Hardware Set (Header Bag) delivered with 2000/2060 Pocket Door Frame from the factory.
2021 Hanger Plate Assembly
$9.71
2020 Door Hanger
$36.89
2055 Track Stop
$9.09
Track Stop for 200 Series Track
1550 Pocket Door Guide Set
$0.63
Jamb Mount Pocket Door Guide Set
1513 Door Bumper
$0.41
Sliding Door Bumper
200 Series Track
From $49.59
511588 Passage End Jamb Bracket (DISCONTINUED)
$1.95
Passage End Pocket Door Header Bracket for DISCONTINUED WOOD STUD 1500PF Series Frames.
512090 Split Stud Floor Bracket
$3.20
Split Stud Floor Bracket for 2060 Series Pocket Door Frame
322066 Self Tapping Drywall Screw Set
$2.90
Self Tapping Drywall Screw Set for All Steel Split Studs.
322060 Split Stud Screw Set
$1.97
Split Stud Screw Set for 2060 Pocket Door Frame
322061 Self Tapping Trim Screw Set
$2.16
Self Tapping Trim Screw Set for All Steel Split Studs. Uses #1 Square Drive Bit
