2060 Series Split Stud Sets

2060 Series All Steel Split Stud Set

Door Heights: 80", 84", 96"

Max Door Thickness: 2-1/4"

Picture of 206068UP 2) 86 3/16" UPRT 1)512090
206068UP 2) 86 3/16" UPRT 1)512090
$84.13
2060 Series All Steel Split Stud Set

Max Door Height: 80"

Net Stud Length: 86-3/8"

Max Door Thickness: 2-1/4"

Manufacturer part number: 206068UP
Picture of 206070UP 2) 90 3/16" UPRT 1)512090
206070UP 2) 90 3/16" UPRT 1)512090
$87.89
2060 Series All Steel Split Stud Set

Max Door Height: 84"

Net Stud Length: 90-3/8"

Max Door Thickness: 2-1/4"

Manufacturer part number: 206070UP
Picture of 206080UP 2)102 3/16" UPRT 1)512090
206080UP 2)102 3/16" UPRT 1)512090
$99.18
2060 Series All Steel Split Stud Set

Max Door Height: 96"

Net Stud Length: 102-3/8"

Max Door Thickness: 2-1/4"

Manufacturer part number: 206080UP
Picture of 206090UP 2)114 3/16" UPRT 1)512090
206090UP 2)114 3/16" UPRT 1)512090
$110.46
2060 Series All Steel Split Stud Set

Max Door Height: 108"

Net Stud Length: 114-3/8"

Max Door Thickness: 2-1/4"

Manufacturer part number: 206090UP
Products specifications
Max. Door Thickness2-1/4"
Max. Door Height80" (6'- 8") [2032mm]
Min. Wall Structure Thickness5-1/2" (2 x 6) [140mm]
Split Stud Construction16 Gauge Cold Rolled Galvanized Steel
PackagingSingle Packed, Reinforced Corrugated Box
Country of OriginU.S.A.
Products specifications
Max. Door Thickness2-1/4"
Max. Door Height80" (6'- 8") [2032mm]
Min. Wall Structure Thickness5-1/2" (2 x 6) [140mm]
Split Stud Construction16 Gauge Cold Rolled Galvanized Steel
PackagingSingle Packed, Reinforced Corrugated Box
Country of OriginU.S.A.
