Products specifications
| Product Grade | Commercial/Residential |
| Application | Interior Residential/Commercial |
| Country of Origin | U.S.A. |
| Track Material | 6063T6 Extruded Aluminum |
| Track Finish | Mill Aluminum |
| Steel Components | 12-14 Gauge |
| Steel Component Finish | Zinc Trivalent Plated |
| Wheel Type | Nylon Encapsulated Sealed Ball Bearing |
| Packaging | Single Packed, Reinforced Corrugated Box |
| Track Profile | I-Beam |
| Hardware Sets | Single Direction Soft Operation |
| Track Length | 48" (4' - 0") [1219mm] |
| Max. Door Width | 24" (2'- 0") [609mm] |
| Min. Soft Close Door Width | 24" (2'- 0") [609mm] |
| Max. Weight Per Door | 330lbs. [150kg] |
| Min. Door Thickness | 1-1/8" |
Related Products
200 Series Track
From $49.59
2027SD-1 Pocket Door Part Set
$84.84
200PD, 200PDSC, 2000, 2000SC, 2060, 2060SC Series Pocket Door Part Set
Auto-Latching Pocket Door Locks
From $10.71
1513 Door Bumper
$0.41
Sliding Door Bumper
1550 Pocket Door Guide Set
$0.63
Jamb Mount Pocket Door Guide Set
2020 Door Hanger
$36.89
2021 Hanger Plate Assembly
$9.71
2055 Track Stop
$9.09
Track Stop for 200 Series Track
Pocket Door Edge Pulls
From $7.55
Pocket Door Edge Pulls provide a finger grip when pulling doors out of a pocket. Edge Pulls are mortised into the door edge and finger grips retract into the door edge when not in use for a clean look.
2066 200 Series Soft Close Kit
$73.95
Single Direction Soft Close Kit (2020 Door Hanger NOT included)Single Direction Soft Operation 330lbs. [150kg] Max. Door Weight 200 Series Track Compatibility Compatible with new version 2020 Door Hanger ONLY 2000, 2060 Series Pocket Door Frame Compatibility 200PD, 200BP, 200MP, 200MD, 200SD, 200SM, 200WM, 200WF, 200WG Series Hardware Compatibility 2066 Installation Instructions
