Products specifications
| Product Grade | Commercial/Residential |
| Application | Interior Residential/Commercial |
| Country of Origin | U.S.A. |
| Track Material | 6063T6 Extruded Aluminum |
| Track Finish | Mill Aluminum |
| Steel Components | 12-14 Gauge |
| Steel Component Finish | Zinc Trivalent Plated |
| Wheel Type | Nylon Encapsulated Sealed Ball Bearing |
| Packaging | Single Packed, Reinforced Corrugated Box |
| Track Profile | I-Beam |
| Hardware Sets | Single Direction Soft Operation |
| Track Length | 60" (5' - 0") [1524mm] |
| Max. Door Width | 30" (2'- 6") [762mm] |
| Min. Soft Close Door Width | 24" (2'- 0") [609mm] |
| Max. Weight Per Door | 330lbs. [150kg] |
| Min. Door Thickness | 1-1/8" |
