| Max. Weight Per Panel | 50lbs. [23kg] w/Mortise Hinge, 30lbs. [14kg] w/Non-Mortise Hinge |
| Application | Interior Residential |
| Panel Thickness | 1-1/8" [29mm] to 1-3/4" [44mm] |
| Steel Component Finish | Zinc Trivalent Plated |
| Mortise Hinge Finish | US3 Bright Brass, US5 Antique Brass, US10 Oil Rubbed Bronze, US15 Satin Nickel |
| Non-Mortise Hinge Finish | Bright Zinc or Brass Tone |
| Steel Components | 12-14 Gauge |
| Product Grade | Residential |
| Country of Origin | U.S.A. |
| Specification Conditions | All product, product specifications and data are subject to change without notice to improve reliability, function or design or otherwise |
