  • 1601 2-Panel Hardware Set, 18"-24" Panel, White Hinge
Picture of 1601 2-Panel Hardware Set, 18"-24" Panel, White Hinge

1601 2-Panel Hardware Set, 18"-24" Panel, White Hinge

$45.92
  • 18" [457mm] 1/6 to 24" [610mm] 2/0 x 2 Individual Panel Width

  • 36" [914mm] 3/0 to 48" [1219mm] 4/0 Opening Width

  • 1-1/8" [29mm] to 1-3/4" [44mm] Panel Thickness

  • 30lbs. [14kg] Max. Weight per Panel

  • Zinc/White Jamb Hinge Finish

    • Manufacturer part number: 1601824W
    Products specifications
    Hardware Sets2-Panel 30lb. Non-Mortise Hinge
    Panels2-Panels
    Max. Weight Per Panel30 lbs. [14kg] (Zinc Tone Non-Mortise Hinge)
    Panel Width18” to 24” x 2<br> (457mm to 610mm x 2)
    Opening Width36" to 48" (3' - 0" to 4' - 0") 914mm to 1219mm
    Products specifications
    Hardware Sets2-Panel 30lb. Non-Mortise Hinge
    Panels2-Panels
    Max. Weight Per Panel30 lbs. [14kg] (Zinc Tone Non-Mortise Hinge)
    Panel Width18” to 24” x 2<br> (457mm to 610mm x 2)
    Opening Width36" to 48" (3' - 0" to 4' - 0") 914mm to 1219mm
