| Max. Weight Per Door | 200lbs. [91kg] |
| Max. Door Width | 36" X 2 (3' - 0" X 2) [914mm X 2] |
| Max. Door Height | 96" (8'-0") [2438mm] |
| Door Thickness | 1-3/8" [35mm] |
| Min. Wall Structure Thickness | 5-1/2" (2 x 6) [140mm] |
| Series Track | 100 |
| Track Finish | Mill Aluminum |
| Track Material | 6063T6 Extruded Aluminum |
| Track Profile | Box Track |
| Hanger Type | Ball Bearing Wheel(200lbs Max.) |
| Wheel Dia. | 1" |
| Wheel Type | Nylon Encapsulated Sealed Ball Bearing |
| Steel Component Finish | Zinc Trivalent Plated |
| Split Stud Construction | 18 Gauge Cold Rolled Galvanized Steel |
| Frame Header Material | Spruce, Pine or Fir (#3 or better) |
| Application | Interior Residential/Commercial |
| Product Grade | Commercial/Residential |
| Packaging | Single Packed, Reinforced Corrugated Box |
| Country of Origin | U.S.A. |
| Specification Conditions | All product, product specifications and data are subject to change without notice to improve reliability, function or design or otherwise |
